Sandwich Structure Outdoor Telecom Cabinet 500W Cooling System With Front / Rear Access

  • 1
  • 2

Brand Name : ESTEL

Model Number : 122070712050001

Certification : ISO9001, CE, 3C, FCC, TLC, IP55

Place of Origin : Shenzhen, China (Mainland)

MOQ : 1 set

Price : Negotiation

Payment Terms : T/T, L/C,D/A, Western Union, Paypal, etc

Supply Ability : 5,000 sets per month

Delivery Time : 15-20 working days

Packaging Details : Wooden case

Cabinet lock : Anti-theft three point lock(support padlock)

Cooling system : 500W cooling capacity air conditioner and two fans.

Protection level : IP55

External size : 650mm×650mm×1200mm(H×W×D)

Material : 1.2mm thick galvanized steel, single wall, with 20mm PEF heat insulation

Package : Wooden case with pallets

Contact Now



Sandwich Structure Steel Outdoor Telecom Cabinet 500W Cooling System With Front And Rear Access



1. Product Features



  • Cabinet type:one compartment.

  • Cabinet dimensions:700mm×650mm×1200mm(H×W×D)

  • 24U 19” mounting rack inside the cabinet

  • Door type:one front door and one back door,with three-point lock(padlock supported)

  • RAL7035 Gray color

  • Material: sandwich structure steel, with 20mm PEF heat insulation

  • Cable Inlet is from the bottom of the cabinet.

  • Grounding bars are on the inner side of the cabinet wall.

  • Cooling system: 500W cooling capacity air conditioner and two fans.

  • IP55 IP rated protection.

  • Floor mounting type or Pole mounting type optional

  • Package: Wooden case with pallets



2. Product Parameters



Item Technical Parameter
Model 122070712050002
Size External Size: 700mm×650mm×1200mm(H×W×D)
Component The whole cabinet is composed of two parts: top cover and cabinet body. The installation method is floor mounted.
Material Sandwich structure steel with insulation.
Structure
  • Sandwich structure with insulation
  • One front door and one back door,hidden zinc alloy hinge
  • Outdoor special steel lock, lock cylinder assembled with protective cover, lock body assembled with three-point lock device
  • Door stopper / wind lock is installed on the inside of the cabinet door
  • Grooved door with seal rubber strip, attached to the inner side of the door, waterproof and dustproof
  • The air inlet and air outlet are all installed with a filter, and the filter can be cleaned and replaced.
  • Include standard 19“ rack inside the cabinet, high universality. Special rack or electrical lining board inside the cabinet can be custom made.
  • Equipped with cable manager
  • Cable inlets at the bottom of cabinet
Surface Treatment Deoil, acid pickling, phosphating, electrostatic spraying, high temperature solidification
Color Outdoor polyester light grey RAL 7035 coating or custom made
Ingress Protection IP55 or custom made
Working Temperature -40°C～+75°C
Compressor Air Conditioner 500W cooling capacity,48VDC
Door Sensor When unlawfully opened, provide real-time alarm.
Illumination LED light, 48VDC



3. Cooling System



3.1Air Conditioner

500W cooling capacity air conditioner,48VDC,which is installed on the front door of the cabinet.



3.2Fans

Two fans,48VDC, which is installed on the top cover of the cabinet.



4. Cabinet Drawings



Sandwich Structure Outdoor Telecom Cabinet 500W Cooling System With Front / Rear Access



5.Cabinet Internal Pictuers



Sandwich Structure Outdoor Telecom Cabinet 500W Cooling System With Front / Rear Access



6. Product Pacakge



Cabinet is packaged in the wooden case.



Sandwich Structure Outdoor Telecom Cabinet 500W Cooling System With Front / Rear Access
