AC220V 50HZ 2300W Outdoor Cabinet Air Conditioner High Precision R22 Noise ≤ 65dB
Quick Details:
| Place of Origin: Shenzhen, China (Mainland) | Rated Cooling Capacity : 2300W |
| Brand Name: ESTEL | Rated Heating Capacity:300/500W (optional) |
| Model: TC06-230JFH/01(KT051) | Dimension: H×W×D 750×500×230mm |
| Product Name: Outdoor Enclosure Air Conditioner | Input Voltage: AC220V/50Hz |
| Certification: ISO9001, CE, 3C, FCC, TLC | Rated Input Current: 2.8A |
| Cover Material: galvanized steel | Rated Input Power: 616W |
| Color: grey | Working Temperature: -20°C ~ +55°C |
| Protection Level: IP55 | Noise: ≤65dB |
| Installation Mode: side mounted, door mounted | Refrigerant: R22 |
| Support OEM | Cooling Method: compressor active cooling |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
| Price: | negotiation |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union |
| Supply Ability: | 1,0000 sets per month |
| Delivery Time: | 7-10 working days |
| Packaging Details: | carton + wooden case +pallet |
1. Specifications
(1) Technical Parameters
| Environmental Performance | working environmental temperature | -20°C ~ 55°C |
| storage temperature | -40°C ~ 70°C |
| working humidity | ≤95% |
| Thermal Performance | rated cooling capacity | 2400W(L35 L35) 2300W(L25 L35) |
| rated heating capacity | 300/500W (optional) |
| Electrical Performance | rated input current | 3.0A(L35 L35) 2.8A(L25 L35) |
| rated input power | 660W(L35 L35) 616W(L25 L35) |
| input voltage | AC220V/50Hz |
| Refrigerant | R22 | |
| Noise | ≤65dB | |
Dimension Diagram: H×W×D: 750×500×230mm
| Size Model | Specs | A | B | C | D | E | F | G | H | I | J | K |
| TC06-230JFH/01 (KT051) | 2300W | 220 | 474 | 460 | 600 | 724 | 750 | 198 | 230 | 700 | 450 | 500 |
Door Hole-opening Diagram(mm):
| Size Model | Specs | L | M | N | O | P | Q | R |
| TC06-230JFH/01(KT051) | 2300W | 474 | 460 | 220 | 724 | 708 | 600 | 460 |
Installation Diagram:
2. Description
TC06-230JFH/01 Air Conditioner is a full automation temperature control product. It uses intelligent controller to control the whole system of the air conditioner. According to the variation of environment temperature, the intelligent controller can automatically detect, operate and record the whole system’s operating time, power consumption, event and historical data. It can store 100 event records and 1280 historical data records, and can enquire 256 days’ daily record information.
3. Application
The cabinet air conditioner is applicable for outdoor cabinets where internal equipment of the cabinet emits a large quantity of heat and is sensitive to the environment temperature and where the indoor environment needs to be isolated from the outdoor environment completely. The product is widely applied in outdoor telecom cabinet, electrical cabinet, battery cabinet, telecom power cabinet, BTS cabinet, network cabinet, outdoor base station cabinet, etc.
4. Features
- Strong adaptability
- High intelligence
- High precision
- High reliability
- Low noise
- Low energy consumption
- With 4 way switching value detection
- With 1 way room air conditioner control
- Voltage input range: 220VAC±15% 50Hz
- With dry contact alarm output
5. System Principle Diagram
6. Electrical Wiring Diagram
Wiring Ports:
L N PE : power supply port (voltage input: 220VAC±15% 50Hz)
F+ F- : direct ventilation output port
AL1 AL2: general alarm output port
A+ B- SGND: RS485 communication port
N: not connected pin
7. Control Board Diagram
ET731 uses English interfaces, which can be operated easily. All the operations can be realized with four buttons. The following is the control board diagram:
(a) Check operating parameters of key parts inside air conditioner, namely observation parameter. Operation steps:
Observation Parameter: on the left of line 1 is Parameter No. (PAnn); on the right of line 1 is parameter value. Line 2 shows the remark of the parameter.
(b) Revise operating parameters of air conditioner, namely control parameters. Operation steps:
Control Parameter: on the left of line 1 is Parameter No. (PCnn), on the right of line 1 is parameter value. Line 2 shows the remark of the parameter.
(c) Revise basic parameters of air conditioner. Operation steps:
Basic Parameter: on the left of line 1 is Parameter No. (PBnn), on the right of line 1 is parameter value. Line 2 shows the remark of the parameter.
(d) Manual Operation Mode:
Operation steps:
Enter the interface to select “Cool” (cooing), “Heater” (heating), “Air” (direct ventilation) to conduct manual start (ON) and stop (OFF) operation.
(e) Event Query Mode:
Operation steps:
8. Mainboard Wiring Diagram
9. Packing and Shipping
Our Delivery Agent
The goods can be shipped by sea, by air, by courier, by land, by train, etc.
Besides the following delivery agent, we can also look for the delivery agent with the best price in china if you need us to do for you.
